Technical product information
One clear specification guide.
Shared product details appear once. Construction differences are grouped only where the selected finish changes them.Wall Cabinet - 27"W x 12"H x 12"D - 2D
- Cabinet line: Unlimited Framed
- Item: W2712GD
- Weight: 18 lb
- Shipping cube: 1
- Assembly eligible: Yes
Construction specifications
Specifications are grouped by the selected finish and consolidated from the published manufacturer specifications.
Aston Green, Iron Black, Treasure Chest
- Door & Drawer Front: Full overlay, 5-piece door & drawer, solid wood with MDF center panel
- Face Frame: 3/4" solid wood frame
- Cabinet Box: 1/2" cabinet grade plywood universal box. You may need to order an additional veneer panel to cover any exposed sides.
- Drawer Box: Solid wood, dovetail construction, 3 1/8" depth
- Drawer Glides: Concealed undermount full extension glides with soft-close feature
- Hinges: 6-way adjustable with soft-close feature
- Exterior Finish: Clear UV coated natural plywood. Need to add BSV, WSV, and USV for exposed parts.
- Interior Finish: Clear UV coated natural plywood
- Shelves: 3/4" thick plywood with front edge banding
- Accessories: Door bumper, metal shelf pin, metal clips, L bracket for base cabinet
- Package: Two boxes packages, universal box & front set.
- Certification: TSCA VI, KCMA, CARB2, NGBS Green
Double Dove White, Lunar Gray, Sage Breeze, Rustic Wood
- Door & Drawer Front: Full overlay, 5-piece door & drawer, solid wood with MDF center panel
- Face Frame: 3/4" solid wood frame
- Cabinet Box: 1/2" cabinet grade plywood box
- Drawer Box: Solid wood, dovetail construction, 3 1/8" depth
- Drawer Glides: Concealed undermount full extension glides with soft-close feature
- Hinges: 6-way adjustable with soft-close feature
- Exterior Finish: Clear UV coated natural plywood. Need to add BSV, WSV, and USV for exposed parts.
- Interior Finish: Clear UV coated natural plywood
- Shelves: 3/4" thick plywood with front edge banding
- Accessories: Door bumper, metal shelf pin, metal clips, L bracket for base cabinet
- Package: Two boxes packages, universal box & front set.
- Certification: TSCA VI, KCMA, CARB2, NGBS Green
Select a finish below. Inventory is confirmed before fulfillment.
Before ordering
Verify measurements, hinge direction, finish, and included components. Cabinet products and components are non-returnable.
